* Figures between () will change depending on the value in the "Minimum display unit" setting.
„ Common settings
Set so the lower limit < upper
limit. The lower limit for the tolerance is
set to a value greater than the
upper limit. Set the tolerance lower limit to a
value that is less than the upper
limit.
Tolerance hysteresis
Illegal input.
Input a value from (0 to 99.9999) *. The tolerance hysteresis field
contains a blank, non-numeric
value, or a value outside the
setting range. Set the tolerance hysteresis field
to a value in the displayed range.
Set so that the (upper limit - lower
limit) > hysteresis. The tolerance hysteresis field is
set to a value greater than the
tolerance measuring range
(upper limit - lower limit). Set the tolerance hysteresis to a
positive value that is less than the
tolerance upper limit - lower limit.
Analog scaling measurement data
Illegal input.
Input a value from (-99.9999 to
99.9999) *. The analog scaling measurement
data field contains a blank, non-
numeric value, or a value outside
the setting range. Set the analog scaling
measurement data field to a
value in the displayed range.
Measurement data 1 and
measurement data 2 cannot be
set to the same value. The measurement data 1 and
measurement data 2 fields for the
analog scaling setting are set to
the same value. Set the measurement data 1 and
measurement data 2 fields for the
analog scaling setting to a
different value.
Analog scaling output voltage
Illegal input.
Input a value from (-10.500 V to
10.500 V). The analog scaling output
voltage field contains a blank,
non-numeric value, or a value
outside the setting range. Set the analog scaling output
voltage field to a value from -10.5
to 10.5.
Analog scaling in general
Set so that |(output voltage 2 -
output voltage 1) / (measurement
data 2 - measurement data 1) | <
10. The slope of the analog scaling
setting exceeds the setting
range. Set the measurement data and
output voltage fields so that the
slope of the analog scaling
setting is less than the displayed
value.
Error message Cause Correction
Data storage points
Illegal input.
Input a value from 1 to (1200000 /
number of storage OUTs). The data storage points field
contains a blank, 0, or a value
greater than 65536. Set the data storage points field
to a value from 1 to 65536.
