3-30
3
3 Window Functions and Operation
(2) Display the measurement data after applying simultaneous auto zero, simul-
taneous reset, or simultaneous timing
Simultaneous zero
Applys auto zero simultaneous to the OUT specified for synchronization.
Simultaneous reset
Resets simultaneous to the OUT specified for synchronization.
Simultaneous timing
Inputs the timing signal simultaneous to the OUT specified for synchronization.
(3) Select display
Click, then check the OUTs to display.
(4) Displays the measurement data after applying auto zero, reset, and timing
processing
Zero
The current measurement data is set to the reference value (zero) and then displayed.
Refer to the LK-G5000 series User's manual, "Chapter 2 Operations during Measurement
and Their Functions" (page 2-1) for details on the auto-zero function.
Reset
The measured values are displayed after the processing in the Measurement Mode and
the Filter processing are reset to the default values.
Refer to the LK-G5000 series User's manual, "Chapter 3 Function Settings" (page 3-1) for
details on the measurement data reset function.
Timing
Toggles the timing function between on and off. Refer to the LK-G5000 series User's
manual, "Chapter 3 Function Settings" (page 3-1) for details on the timing function.
(5) Head status
Displays the head status.
Refer to the LK-G5000 series User's manual, "Chapter 2 Operations during Measurement
and Their Functions" (page 2-1) for details on the displayed information.
(6) Help
Opens the LK-Navigator 2 help file.
(7) Exit
Closes the "Measurement Value Display".
