3-15
3
3 Window Functions and Operation
Display, Analog
(1) Display
Minimum display unit
Sets the decimal point position and number of digits to display for measured and setting
values.
Digits not displayed below the decimal point are rounded off.
These settings are initialized when the "Minimum display unit" setting is changed:
Scaling, offset, tolerance setting, analog output scaling, auto zero reference value.
(2) Analog output scaling
Sets the scaling for the analog output with respect to the measurement data.
Analog outputs can be scaled within a range of ±10.5 V.
(1)
(2)
Reference
NOTE
Reference
