KEYENCE LK-H2 - Manual (Page 64)

3-40
3
3 Window Functions and Operation
Changing "No. of used heads" and "No. of
used OUT" in the settings file (LK-Backup)
LK-Backup allows values for "No. of used heads" and "No. of used OUT" to be changed
without initializing measurement settings.
1
Save the current settings file in LK-Navigator (page 3-39).
2
Launch LK-Backup by double-clicking the LK-Backup shortcut icon.
3
Click "Open", then select the saved settings file.
4
Change the values for "No. of used heads" and "No. of used OUT", and click "Save".
5
Enter a file name and select a directory in which to save the file, then click "Save".
6
Load the settings file with the changed "No. of used heads" and "No. of used OUT"
values using LK-Navigator (page 3-39).
