3 Window Functions and Operation
Flow of Operation
This explanation will outline the procedures to set the input for HEAD01 to OUT01 after
launching LK-Navigator 2.
1
Connect the controller and PC with an RS-232C cable, LAN cable, or USB cable.
2
Start the controller, then start the PC.
3
Launch LK-Navigator 2 (page 2-9).
4
At the "Select startup configuration setting", select "Start up with the default values"
5
In the "Controller Environment Setting", specify the number of heads, OUTs, and
analog outputs being used. (page 3-24).
6
In the "Communication settings", configure the communication method to use with
the controller (page 3-26).
7
Select a program number (page 3-27).
8
Specify the "Common Settings" (page 3-16).
9
Configure "HEAD01" (page 3-5).
10
Configure "OUT01" (page 3-5).
11
Confirm the settings in the "Settings List" (page 3-22).
12
Download the settings to the controller (page 3-23).
13
Use tools to monitor operation (page 3-29 to page 3-33).
14
Save the settings file on the PC (page 3-39).
This completes the most typical operations.
