2-10
2
2 Preparations before Operating
Refer to the following explanations before selecting the other options.
• "Read from file": Refer to "Read from file" (page 2-10).
• "Read controller settings": Refer to "Read controller settings" (page 2-10).
3
Click "OK".
The program initializes.
Read from file
4
At the "Select startup configuration setting" dialog, select "Read from file".
5
Click "OK".
The "Open file " dialog appears.
6
Select the settings file to load.
7
Click "Open".
The settings are read.
Clicking "Cancel" results in the same operation as "Start up with the default values". (page 2-9).
Read controller settings
1
At the "Select startup configuration setting" dialog, select "Read controller settings".
2
Click "OK".
The settings are read from the controller.
This communication uses the last used settings when LK-Navigator 2 was closed before.
• If a controller is not connected or communication fails, an error message will be displayed.
• When LK-Navigator 2 is launched for the first time, it is set to the following communication setting.
Interface: USB
• A communication failure will result in the same operation as "Start up with the default values" (page
2-9).
Reference
Reference
Reference
NOTE
