3-34
3
3 Window Functions and Operation
(1) Start Storage
Starts storing data on the controller.
(2) Stop Storage
Stops storing data on the controller.
(3) Clear Stored Data
Clears the data stored on the controller.
Clear storage data clears all data stored on the controller.
(4) Status display
Displays the status of data storage on the controller.
The following states are displayed:
(5) Data Storage Setting
Sets the method for storing measurement data. Refer to "Data Storage Setting" (page 3-
33) for details.
(6) Storage Data Readout
Loads storage data from the controller. Refer to "Loading storage data" (page 3-38) for
details.
(7) Waveform display manipulating tool bar
Tile/cascade display
Sets whether to display measurement data waveforms tiled or cascaded.
Zoom/shrink
Zooms/shrinks the measurement data waveform vertically and horizontally.
Auto fit
Automatically adjusts the vertical scale to fit the display area.
Move display position
Moves the waveform up or down.
Status Status displayed Number of storage data displayed
Disconnected Not connected *****
Normal mode: storage Storage in progress Currently stored number of data
Normal mode: stopped Stopping in progress Currently stored number of data
Communications error ***** *****
Other system errors System error *****
NOTE
Reference
