3-36
3
3 Window Functions and Operation
Data storage setting flow
1
Click "Data Storage Setting".
Preset the target OUT, amount of data store, and storage cycle.
Refer to "Changing data storage settings" (page 3-37) for details.
2
Click "Start Storage".
The controller starts storing measurement data.
Storage stops automatically when number of data set in "Amount of Data Stored"
has been stored.
• Click "Stop Storage" to pause data storage.
• After pausing, clicking on "Start Storage" again will resume data storage from where it
was paused.
3
Click "Storage Data Readout".
The "Read accumulation data" dialog appears.
Refer to "Loading storage data" (page 3-38) for details on loading storage data.
4
Click "Readout".
The data stored in the controller is transferred to the PC.
When the transfer status bar graph reaches the right end, the data transfer is
complete.
Reference
