PeCifiCaTions
ALL FRAME
™
Multi-Modular I/O System
C2dio Digital I/O Card Specifications
Channels 4 AES3 inputs 4 AES3 outputs
AES3 Inputs Two XLR female, Channels 1/2 and 3/4;
One bi-color clock LED for Channels 1/2;
Channels 1/2 can be used as a clock source
AES3 Outputs Two XLR male, Channels 1/2 and 3/4;
Word Clock I/O One BNC connector;
One bi-color LED;
3-position slide switch allows the BNC jack to be set for
Word Clock Out (O), Word Clock In (I), or Word Clock In with
Termination (T)
Word Clock Input Sensitivity: 0.2 to 5Vp-p
Impedance: 75 ohms/70k ohms selectable
Clock Sources Internal (Network), Work Clock, AES3;
AES3 Clock connects to Inputs 1/2 only
Jitter
Attenuation
Well below AES3 Jitter Transfer Function Mask
Network Sample Rates 1x: 39.7–52kHz;
2x: 79.4–104kHz
Sample Rate Conversion Can convert input sample rates between 28.0kHz and
216.0kHz to any supported system sample rate
THD+N: less than 130dB for full scale signals
Sample Rate Conversion
Time
Less than 0.42 ms (at all system sample rates)
Dimensions 5.2 x 1.9 x 3.01 in. (132.08 x 48.26 x 76.45 mm)
Weight 0.5 pound (0.22 kg)
