Dimensions - POA80

3.038 in.,

77.21 mm

5.843 in.,

148.41 mm

7.00 in.,

177.8 mm

.579 in.,

14.70 mm

.550 in.,

13.97 mm

.876 in.,

22.25 mm

11.500 in.,

292.1 mm

.187 x 3.50 in.,

4.74 x 8.89 mm

Slot

.949 in.,

24.10 mm

6.550 in.,

166.37 mm
