83 s
PeCifiCaTions
ALL FRAME
™
Multi-Modular I/O System
C4o Line Output Card Specifications
Channels 4 outputs Mic- or line-level
XLR Outputs Pin 1: Shield; Pin 2: Hot; Pin 3: Cold
Output Impedance: 450 Ohms for +4dBu, +18dBu, +24dBu and +28dBu outputs;
200 Ohms for Mic
Output Levels: +28dBu, +24dBu, +18dBu, +4dBu, and Mic
Frequency Response -3dB: 2Hz and 23kHz
±0.5dB: 10Hz-22kHz (at 1x sample rate)
THD +N < .002% at -10dBFS
Signal to Noise: D/A: -111dB (unweighted)
Crosstalk <100dB at 1kHz
Threaded inserts PEM FEOX-440;
Use size #4 machine screw with 40 threads per inch.
Dimensions 5.2 x 1.9 x 3.01 in.
132.08 x 48.26 x 76.45 mm
Weight 0.5 pound (0.22 kg)
