[Example 3] When both Group No. and Device No. are set to Broadcast

DEQ5 (Transmitting side)

o

DEQ5E (Receiving side)

i

Group No.*(Broadcast)
Device No. ‘(Broadcast)

DEQ5E (Receiving side)

GROUP No. 1
DEVICE No. 1

GROUP No. 1

DEVICE No. 2

DEQ5E (Receiving side)

GROUP No. 2

DEVICE No. 1

o

DEQ5E (Receiving side)

GROUP No. 2
DEVICE No. 2

DEQ5E (Receiving side)

GROUP No. 3
DEVICE No. 1

DEQ5E (Receiving side)

GROUP No. 3

DEViCE No. 2

When the setting of DEQ5 remote address are made as shown above, all the DEQSEs respond to the remote

control signal received from DEQ5.

55
