Appendix A: SkyView System Specifications
13-2
SkyView Pilot’s User Guide - Revision S
Inputs, Outputs, and
Communication Ports
(1) Primary power and ground input
(1) Backup battery (SV-BAT-320) input
(5) Serial RS-232 Ports
(Left and Right) Audio outputs
(4) Contact inputs
(3) USB Ports (2 on back, 1 on main display harness)
(2) SkyView Network Ports
SV-ADAHRS-20X Quick Specifications
Mechanical
4.71” wide x 1.22” tall x 2.61” deep (120 x 31 x 67 mm)
8.2 oz. (0.23 kg)
Operating Temperature
-22° to 140° F (-30° to +60° C)
Connections
(1) 9-pin D-sub male connector
(1) 2-wire connector
(3) 1/8” NPT female threaded fittings
Sensor Inputs
(1) 2-wire OAT for use with SV-OAT-340
Pitot, Angle of Attack, and Static pressure ports
Other Inputs, Outputs,
and Communication
Ports
(1) SkyView Network Port
SV-ADSB-470 Quick Specifications
Mechanical
7.00” wide x 1.19” tall x 4.63” deep (118 x 30 x 11 mm)
.77lbs. (350g)
Operating Temperature
-22° to 140° F (-30° to +60° C)
Connections
(1) 9-pin D-sub female connector
(1) Antenna connector (BNC)
ADS-B Input Capabilities
ADS-B traffic and weather via 978 MHz (UAT) frequencies:
US only.
