8-18
SkyView Pilot’s User Guide - Revision S
Pressing the button for any active mode (except an external LEVEL button or SV-AP-
PANEL LEVEL button) turns off that mode and any armed mode for the axis, turns off the
flight director and disengages the servo for the axis.
Pressing the button for any armed mode disarms that mode.
Expert Autopilot Roll Modes
The following table summarizes the different autopilot modes of operation for the roll axis.
Mode
Annunciation
Description
Control
Roll Hold
ROLL
Holds the current aircraft roll angle.
Default mode or
ROLL HOLD button
Heading
HDG
042
Holds the selected magnetic heading
target.
HDG button
Track
TRK
042
Holds the selected GPS ground track
target.
TRK button
NAV (GPS)
Armed
GPS
Captures the selected navigation
source from the active ROLL, HDG or
TRK mode. The Autopilot will
automatically sequence and activate
the armed mode when the autopilot
determines that it can capture the CDI.
NAV button
NAV (GPSS)
Armed
GPSS
NAV (VOR)
Armed
VOR
NAV (LOC)
Armed
LOC
NAV (GPS)
Active
GPS
Tracks the selected navigation source.
Automatically
sequenced from
the NAV armed
mode.
NAV (GPSS)
Active
GPSS
NAV (VOR)
Active
VOR
NAV (LOC)
Active
LOC
Level Mode
STRAIGHT
Holds the aircraft in a wings level
attitude.
LEVEL menu
button or optional
external Level
button.
Figure 195 - Expert Autopilot Roll Modes
HDG
In this mode, the roll axis will fly the selected heading via the HDG (heading) bug.
The HDG bug value is not synchronized unless you manually synchronize the HDG bug or utilize
Control Wheel Steering (see section below for detail). This allows you to pre-select headings in
an IFR environment before you want to actually fly to them.
