88 Managing Device assignments Welch Allyn
Figure 13-1: Devices tab example with one device
8. Click Edit near the bottom of the window.
9. Click on the Serial Number of the recently connected CVSM. The Device
Configuration window populates with information from the selected CVSM.
a. Devices which are currently in use appear with a wave symbol on the left
side.
b. Devices which are idle do not appear with a wave symbol on the left side.
Assignment of devices can only be taken when a device is not currently in use.
10. Use the Location drop down menu to select a Unit name to assign the device. An
example is shown in “Figure 13-2: Device Location assignment drop down menu
example” on page 89.
Typically assignments for devices are made on an Unit basis. This allows clinical
user flexibility to move the device from any room/bed location throughout the
covered area.
