26 Connex Server Startup Welch Allyn
To launch the Corepoint Administration console:
1. Go to Start > Programs > Corepoint Integration Engine > Administration to start
the administration console within an Internet Explorer browser window.
2. Login with user name and password.
3. Click on Connections tab near the top left of the window to view current connection
states. An example is shown below.
Figure 5-7: Corepoint administration console connections initial view
4. Some simple view changes may provide a simpler way to view connection data.
a. The typical view displays connections in terms of grouping. As the application is
only being used with Connex, the grouping view contains additional information
which is not needed.
b. In the drop down menu next to Grouping, select the option for No Groups.

c. Click on in the upper right corner to customize the columns to view. A drop
down menu appears.
d. Items selected for view have a ✓ next to them are selected for inclusion in the
view.
e. Use the drop down menu and select Backlog to remove.
f. Use the drop down menu and select Peer and Port to add.
g. An updated view example is shown in “Figure 5-8: Corepoint administration
console connections updated view” on page 27 below.
h. The next time the administration console is accessed, it will retain the last know
view.
