Kontron NSN2U IP Network Server User Manual
Page 73
72
Key
Description
↑
Select Item up - The up arrow is used to select the previous value in
a menu item’s option list, or a value field pick list. Pressing the
Enter key activates the selected item.
↓
Select Item down - The down arrow is used to select the next value in
a menu item’s option list, or a value field pick list. Pressing the
Enter key activates the selected item.
F5/-
Change Value - The minus key or the F5 function key is used to change
the value of the current item to the previous value. This key scrolls
through the values in the associated pick list without displaying the
full list.
F6/+
Change Value - The plus key or the F6 function key is used to change
the value of the current menu item to the next value. This key
scrolls through the values in the associated pick list without
displaying the full list. On 106-key Japanese keyboards, the plus key
has a different scan code than the plus key on the other keyboard,
but it has the same effect.
selected feature is a submenu, or to display a pick list if a
selected feature has a value field, or to select a sub-field for
multi-valued features like time and date. If a pick list is
displayed, the Enter key undoes the pick list and allows another
selection in the parent menu.
Exit - The ESC key provides a mechanism for backing out of any field.
This key undoes pressing the Enter key. When the ESC key is pressed
while editing a field or selecting menu features, the parent menu is
re-entered. When the ESC key is pressed in any submenu, the parent
menu is re-entered. When the ESC key is pressed in any major menu,
the exit confirmation window is displayed and the user is asked
whether changes can be discarded.
Setup Defaults - Pressing F9 causes the following message to appear:
Setup Confirmation
Load default configuration now?
[Yes
If Yes is selected and the Enter key is pressed, all Setup fields are
set to their default values. If No is selected and the Enter key is
pressed, or if the ESC key is pressed, you are returned to where you
were before F9 was pressed without affecting any existing field
values.
] [No]
Save and Exit - Pressing F10 causes the following message to appear:
Setup Confirmation
Save Configuration changes and exit now?
[Yes] [No]
