11
NMI
Front Panel LEDs
Power status
Chassis identification
System status
Fan status
HDD activity/fault
NIC activity
Power Supply Up to two 600-W power supply modules (AC or DC)
Fans
Four redundant, hot-swappable CPU/memory area cooling
fans
Two redundant, hot-swappable PCI area cooling fans
Two optional redundant power supply fans (with PS
redundancy configuration only)
System Management
On-board ServerEngines* LLC Pilot II Controller
Integrated Baseboard Management Controller (Integrated
BMC), IPMI 2.0-compliant
Integrated Super I/O on LPC interface
2.1 Server Components
Figure 2 shows the NSN2U Server with top covers and front bezel removed to show the
internal components.
Figure 2. IP Network Server NSN2U Components
