Remove the riser card assembly (so the processor air duct can be removed). For

Open the DIMM slot levers for the DIMM you want to remove.

Using both hands, hold the DIMM by the edges and lift it up from the slot. Store

the DIMM in an anti-static package.

If you are installing a replacement DIMM in this slot, return to Step 5 in

Otherwise, replace the air duct, riser card assembly, and back chassis cover if

you have completed all work inside the server.

Adding or Replacing a Processor

CAUTION: The processor must be appropriate: You could damage the server board if you

install a processor that is inappropriate for your server. Refer to the

(search for NSN2U, click on Product Downloads, then Ordering Guide) for a list of

compatible processors for the NSN2U Server.

Use the instructions provided below to add or replace a processor instead of using the

instructions that came with the processor. Before you begin, remove the riser card

in this chapter

Follow the instructions below to remove and then install a processor, referring to

Figure 25

through

Figure 32

ESD and Processor Handling Precautions

Be mindful of the following points when handling the processors and sockets:
•

Reduce the risk of electrostatic discharge (ESD) damage to the processor by doing

the following:

— Touch the metal chassis before touching the processor or server board.
— Keep part of your body in contact with the metal chassis to dissipate the

static charge while handling the processor.

— Avoid moving around unnecessarily.
— Use a ground strap attached to the front panel (with the bezel removed.)

•

When opening a socket, do not touch the gold socket wires.

•

When unpacking a processor, hold it only at the edges to avoid touching the gold

contacts.
