ULNM with VMware ESX Server 4.0 /4.1
106
Dell ULNM Network Configuration Prerequisites
All hardware elements must have an operational network configuration that allows free dialog between
them. Connections through the following ports must be authorized within the firewall of the main
operating system:
• Connections on tcp port 4679 and 4680 to enable a remote access for supervision and configuration
through Web browser. These ports are reserved at IANA (http://www.iana.org/).
• Connections through TCP port 80 must be opened as a destination port (for output) on the machine
hosting Dell ULNM
In order to enable communication between Dell ULNM and the Dell Network Management Card
(command line for firewall):
esxcfg-firewall -o 4679,tcp, in,DELLhttp
esxcfg-firewall -o 4680,tcp, in,DELLhttps
esxcfg-firewall -o 80,tcp,out,http
esxcfg-firewall -o 5000,tcp,out,DELLinit
esxcfg-firewall -o 4679,udp, in,DELLhttpU
esxcfg-firewall -o 4680,udp, in,DELLhttpsU
• In order to enable communication between Dell ULNM and the Dell UPS Network Management Card
(command line for firewall 2):
esxcfg-firewall -o 161,udp, in,DELL-ULNM
esxcfg-firewall -o 200,udp, in,DELL-ULNM
esxcfg-firewall -o 2844,udp, in,DELL-ULNM
esxcfg-firewall -o 2845,udp, in,DELL-ULNM
esxcfg-firewall -o 161,udp,out,DELL-ULNM
esxcfg-firewall -o 200,udp,out,DELL-ULNM
esxcfg-firewall -o 2844,udp,out,DELL-ULNM
esxcfg-firewall -o 2845,udp,out,DELL-ULNM
NOTE:
To configure the VMware ESX Server for the network, please refer to the VMware ESX user’s manual.
