Supervision 72
AC/DC DC/AC Bypass Gray Status OK and Inactive or Unknown
Battery Modules
Green Status OK
Orange Battery charge is less than 50%
Red Battery fault or End-of-backup
Gray Battery status unknown
Electrical Flows
Yellow Current flow through the cable
NOTE: The object animation gives the direction of
the current flow.
Gray No current flow through the cable
WARNING: The cable may be under voltage.
Electrical Power Source at UPS Input
Green Source powered. Status OK
Gray Source not powered or status unknown
Load at UPS Output
Green Load powered and protected. Status OK
Red Load not powered
Table 7. Synoptic Panel Icons
