Configuration 40
5 Click Save.
Figure 21. Edit UPS Configuration Dialog Box
The Edit UPS Configuration dialog box is available for some UPSs connected through USB or serial.
Otherwise, the parameters are displayed as “read only” through the network or if the UPS does not
support this feature.
You can configure following UPS parameters:
• Low Battery alarm level
• Load Segment restart delays
• Audible alarm
Test Access
Test access checks if the login and password are correctly configured so that:
• Dell ULNM can update his shutdown configuration on the card
• Dell ULNM can remotely access to the Dell ULNM Shutdown Controller
Test Shutdown
Test shutdown starts a shutdown procedure according to the Dell ULNM parameters.
WARNING:
This action will launch the entire shutdown sequence, including the UPS shut off.
