7.4.3 Math Tool
The Math tool provides basic arithmetic, inequality expressions, and statistical information for PresencePLUS
inspections. In general, the Math tool takes one or more pieces of information from Vision tools and makes
mathematical espressions out of them. The results of the Math tool's analysis are displayed in the Result
windows at the bottom of the screen.
The inputs to the Math tool are called Operands. The Operation is the mathematical expression used to analyze
the Operands.
Fields
The following are fields on the Math tool Input tab:
•
Math Tool Modes7.4.3.1 Math Tool Modes
on page 139
•
Use of Constants7.4.3.2 Use of Constants
on page 143
•
on page 143
