7.2.2 Geometric Find Tool
The Geometric Find tool uses edge content to locate the best matching shape in a search area of an image.
During setup, the you identify a reference shape within a search area for the Geometric Find tool. This reference
shape is subsequently used to locate like shapes in new images by searching for shapes similar to the reference
shape.
Tools that follow the Geometric Find tool translate and rotate their ROIs relative to positional information from
the Geometric Find tool. Geometric Find returns the location of the best shape found.
