BCR/BCR
1.3 GEO/GEO
1.3 EDGE/EDGE
1.3 AREA/AREA1.3 OMNI/OMNI
1.3 OMNI
Color ProII/ProII
1.3 ProII
Color Location
Tools
Communication
Tool
on
page 118
Yes Yes Yes Yes Yes Yes Yes Yes Math
Tool7.4.3
Math Tool
on page
138
Yes Yes Yes Yes Yes Yes Yes Yes Measure
Tool7.4.4
Measure
Tool
on
page 143
Yes No No No Yes Yes Yes Yes #unique_151
Yes Yes Yes Yes Yes Yes Yes Yes Test
Tool7.4.5
Test Tool
on page
164
7.4.1 Communication Tool
The Communication tool is used to conditionally export data from the Sensor to an external device. Results
from Vision tools can be selected by the Communication tool and exported to an external device. The Sensor
can export data over the Ethernet or via its serial channels.
Examples of exported results
• Execution times
• Whole-number counts
• Input and output values from a Test tool
• Success from Locate and Test tools
• Reference point-to-edge and rotation distances
Fields
The following are fields on the Communication tool Input tab:
• Select7.4.1.2 Select on page 120
• Connections 7.4.1.3 Connections on page 120
• Format7.4.1.4 Format on page 121
• Output Filter7.4.1.5 Output Filter on page 121
• Guidelines for Configuring the Communication Tool7.4.1.6 Guidelines for Configuring the
Communication Tool
on page 121
Supported Platforms
P/N 000000 Banner Engineering Corp. - Minneapolis, MN USA - www.bannerengineering.com
Tel: 763.544.3164
118
7/2009 PresencePLUS Software Tools
