Port Default IP Address Socket
20,003 192.168.0.1 4
20,004 192.168.0.1 5
20,005 192.168.0.1 6
20,006 192.168.0.1 7
20,007 192.168.0.1 8
20,008 192.168.0.1 9
20,009 192.168.0.1 10
• The serial port is the RS-232 connector (Pins 1, 9, and 10) on the Sensor. The deafult settings
for the serial port are listed below.
Default Setting Attribute
115200 Baud Rate
8 Data Bits
None Parity
1 Stop Bit
None Flow Control
3. Format the ASCII string of data (in the Format field).
• Choose a Delimiter and Start and End strings.
• Check the Enable Labels box to add the names for data being sent.
Allowable ASCII string options are shown below.
Note: Start and End strings can now accept ASCII Hex values, and the following special
characters: "\r", "\n", "\t".
Description Values Option Name
The delimiter is used to separate
the individual pieces of data being ,
: < Colon>
Delimiter
sent. The delimiter will follow every
; individual segment of data,
including start string and end
string.
\r\n Carriage return and
then line feed
\n\r Line feed then
carriage return
\r Carriage return only
\n Line feed only
