Description Value Data Label
-1 = Input1 results not defined.
1 = Input 2 results passed.
0 = Input 2 results failed.
1, 0, or -1 Input2
-1 = Input2 results not defined.
1 = Input 3 results passed.
0 = Input 3 results failed.
1, 0, or -1 Input3
-1 = Input3 results not defined.
1 = Input 4 results passed.
0 = Input 4 results failed.
1, 0, or -1 Input4
-1 = Input4 results not defined.
1 = Tool overall results passed.
0 = Tool overall results failed.
1 or 0 Output
7.4.2 Coordinate Tool
The Coorodinate tool takes coordinate values from different vision tools and combines then into a single output
representing object x and y coordinates as well as a rotational offset from a default position defined in the
inspection.
The Coordinate tool can accept x, y coordinates, and angle (Theta) data from any tool that produces locational
information as part of the results:
• Locate tool
• Geometric Find tool
• Pattern Find tool
• Blob Find tool
• Blob Detect tool
• Color Blob tool
• Pattern Count tool
• Geometric Count tool
• Edge tool
• Object tool
• Barcode tool
• BCR tool
• Measure tool
• Math tool
Note: The Coordinate tool also accepts user-defined constants for any of these values.
Additionally, not all tools (for example, Barcode) produce angle data.
