Communication Tool Exportable Results: Edge Tool
Description
Value
Data Label
User-defined name
string
Tool Name
Tool processing time for the current inspection.
ms
Execution Time
Fastest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Min
Slowest recorded tool processing time since the start of the
inspection or since power-up.
ms
Execution Time Max
Total number of bright-to-dark edges.
whole number
Bright-to-Dark Count
Total number of dark-to-bright edges.
whole number
Dark-to-Bright Count
Total number of all edges.
whole number
Total Edge Count
X, Y coordinates of all the edges found.
pixels (X, Y)
Location(s)
Communication Tool Exportable Results: Geometric Count Tool
Description
Value
Data Label
User-defined name
string
Tool Name
1 = Tool executed successfully
0 = Tool did not find a point to use as a reference
1 or 0
Success
Tool processing time for the current inspection.
ms
Execution Time
Fastest recorded tool processing time since the start of the inspection
or since power-up.
ms
Execution Time Min
Slowest recorded tool processing time since the start of the inspection
or since power-up.
ms
Execution Time Max
Total number of patterns above the minimum acceptance leval and
below the maximum number of patterns.
whole number
Match Count
X, Y coordinates of the point from ROIs will rotate.
pixels (X, Y)
Rotation Origin
Rotational value of the first pattern found.
degrees
Match Rotation
X, Y coordinates of the first pattern found.
pixels (X, Y)
Best Match Location
Point
Percent match of the first patttern found.
20-100%
Best Match %
Communication Tool Exportable Results: Object Tool
Description
Value
Data Label
User-defined name
string
Tool Name
Tool processing time for the current inspection.
ms
Execution Time
Fastest recorded tool processing time since the start
of the inspection or since power-up.
ms
Execution Time Min
