4.1 Exploratory mode overview
757 VA Computrace – Software
55
4 Exploratory mode
4.1 Exploratory mode overview
Exploratory mode features
The program part "Exploratory" has been especially designed for
practice-oriented
qualitative voltammetric analysis. It com-
prises seven different measurement techniques and is curve ori-
ented. You are shown voltammograms and the associated pa-
rameters in two windows next to each other. The various voltam-
mograms can be superimposed on one another thus making
comparison of the curves extremely simple.
Peaks or waves of the measured curves can be evaluated auto-
matically or manually after setting the base points. Tracing the
curves with a cursor allows the measured current and voltage
values to be accessed.
Thanks to its possibilities, this program part is helpful in the de-
velopment and optimization of methods for the quantitative de-
termination of substances. The optimized voltammetric parame-
ters can be transferred directly to the working method in the pro-
gram part "Determination".
Exploratory mode selection
MAIN WINDOW / Mode / Exploratory
Switching to the exploratory mode for recording
and displaying of signals.
Exploratory mode windows
MAIN WINDOW / Window / Exploratory specification (F11)
The
EXPLORATORY SPECIFICATION
window will
be opened or (if it is already open) closed.
MAIN WINDOW / Window / Exploratory curves (F12)
The EXPLORATORY CURVES window will be
opened or (if it is already open) closed.
