3.5 Graphical settings
757 VA Computrace – Software
51
Axis properties
The axis properties for the x and y axis of all curve windows can
be set with the
x axis or y axis tab of the GRAPHICAL PROPERTIES
window.
Range (for x axis)
From [ -5...+5 V ; -1 V ]
Lower limit for x axis (voltage).
To [ -5...+5 V ; -1 V ]
Upper limit for x axis (voltage).
Range (for y axis)
From [ > 0 ; -1e-10 ]
Lower limit for y axis
(current for VA techniques, dt/dE for PSA).
To [ > 0 ; 1e-10 ]
Upper limit for y axis
(current for VA techniques, dt/dE for PSA).
Style
Font for description of the x or y axis.
Selection of line style of the x or y axis in the LINE
PROPERTIES window (see page 54).
Font for labels of the x or y axis.
