LDAT-Series Integrated Linear Thrusters 75
Rockwell Automation Publication LDAT-IN001A-EN-P - August 2012
Specifications
Linear Thruster Weights
Linear Thruster
(frame 30) Cat. No. Weight,
approx
kg (lb) Linear Thruster
(frame 30) Cat. No. Weight,
approx
kg (lb) Linear Thruster
(frame 30) Cat. No. Weight,
approx
kg (lb)
LDAT-S031010-xx 6.9 (15.2) LDAT-S032010-xx 9.7 (21.5) LDAT-S033010-xx 12.6 (26.9)
LDAT-S031020-xx 7.5 (16.6) LDAT-S032020-xx 10.3 (22.8) LDAT-S033020-xx 13.2 (30.4)
LDAT-S031030-xx 8.1 (17.9) LDAT-S032030-xx 10.9 (24.1) LDAT-S033030-xx 13.8 (31.7)
LDAT-S031040-xx 8.7 (19.2) LDAT-S032040-xx 11.6 (25.5) LDAT-S033040-xx 14.4 (31.7)
Linear Thruster
(frame 50) Cat. No. Weight,
approx
kg (lb) Linear Thruster
(frame 50) Cat. No. Weight,
approx
kg (lb) Linear Thruster
(frame 50) Cat. No. Weight,
approx
kg (lb)
LDAT-S051010-xx 10.3 (22.7) LDAT-S052030-xx 16.5 (36.4) LDAT-S053050-xx 22.7 (50.1)
LDAT-S051020-xx 11.3 (24.8) LDAT-S052040-xx 17.5 (38.5) LDAT-S054010-xx 23.3 (51.3)
LDAT-S051030-xx 12.2 (26.9) LDAT-S052050-xx 18.4 (40.6) LDAT-S054020-xx 24.2 (53.4)
LDAT-S051040-xx 13.2 (29.0) LDAT-S053010-xx 18.9 (41.6) LDAT-S054030-xx 25.2 (55.5)
LDAT-S051050-xx 14.1 (31.7) LDAT-S053020-xx 19.8 (43.7) LDAT-S054040-xx 26.1 (57.6)
LDAT-S052010-xx 14.6 (32.2) LDAT-S053030-xx 20.8 (45.8) LDAT-S054050-xx 27.1 (59.7)
LDAT-S052020-xx 15.6 (34.3) LDAT-S053040-xx 21.8 (48.0)
Linear Thruster
(frame 75) Cat. No. Weight,
approx
kg (lb) Linear Thruster
(frame 75) Cat. No. Weight
approx
kg (lb) Linear Thruster
(frame 75) Cat. No. Weight
approx
kg (lb)
LDAT-S072010-xx 17.7 (39.1) LDAT-S073040-xx 26.6 (58.7) LDAT-S074070-xx 35.5 (78.2)
LDAT-S072020-xx 18.9 (41.8) LDAT-S073050-xx 27.8 (61.4) LDAT-S076010-xx 38.6 (85.1)
LDAT-S072030-xx 20.2 (44.4) LDAT-S073060-xx 29.1 (64.1) LDAT-S076020-xx 39.8 (87.7)
LDAT-S072040-xx 21.4 (47.1) LDAT-S073070-xx 28.2 (62.1) LDAT-S076030-xx 41.0 (90.4)
LDAT-S072050-xx 22.6 (49.8) LDAT-S074010-xx 30.3 (66.8) LDAT-S076040-xx 42.2 (93.1)
LDAT-S072060-xx 23.8 (52.2) LDAT-S074020-xx 29.4 (64.8) LDAT-S076050-xx 43.5 (95.8)
LDAT-S072070-xx 25.0 (55.2) LDAT-S074030-xx 30.6 (67.5) LDAT-S076060-xx 44.7 (98.5)
LDAT-S073010-xx 23.0 (50.7) LDAT-S074040-xx 31.8 (70.2) LDAT-S076070-xx 45.9 (101.2)
LDAT-S073020-xx 24.2 (53.3) LDAT-S074050-xx 33.1 (72.9)
LDAT-S073030-xx 25.4 (56.0) LDAT-S074060-xx 34.3 (75.6)
