58 LDAT-Series Integrated Linear Thrusters
Rockwell Automation Publication LDAT-IN001A-EN-P - August 2012
3 Clevis, Female 30 LDAT-S03-CLVSF 75 (2.65)
50
LDAT-S0507-CLVSF 100 (3.53)
75
100
LDAT-S1015-CLVSF 250 (8.82)
150
Slider-end Accessories
Accessory Item Frame Cat. No. Weight, approx g (oz)
4 Rod Clevis Kit 30 LDAT-S03-RODCLVS 190 (6.70)
50
LDAT-S0507-RODCLVS 320 (11.29)
75
100
LDAT-S1015-RODCLVS 770 (27.16)
150
5 Rod Eye Kit 30 LDAT-S03-RODEYE 150 (5.29)
50
LDAT-S0507-RODEYE 260 (9.17)
75
100
LDAT-S1015-RODEYE 590 (20.81)
150
6 Rod Coupler Kit 30 LDAT-S03-RODCPLR 290 (10.05)
50
LDAT-S0507-RODCPLR 370 (13.05)
75
100
LDAT-S1015-RODCPLR 1030 (36.33)
150
7 Horizontal Payload
Mounting Bracket 30 LDAT-S03-HPBRKT 260 (9.17)
50
LDAT-S0507-HPBRKT 430 (15.17)
75
100 LDAT-S10-HPBRKT 910 (32.10)
150 LDAT-S15-HPBRKT 1300 (54.86)
8 Counterbalance Kit 30 LDAT-S03-CBRKT 380 (13.4)
50
LDAT-S0507-CBRKT 600 (21.2)
75
100 LDAT-S10-CBRKT 950 (33.5)
150 LDAT-S15-CBRKT 1160 (40.9)
Mounting Accessories (continued)
Accessory Item Frame Cat. No. Weight, approx g (oz)
