LDAT-Series Integrated Linear Thrusters 7

Rockwell Automation Publication LDAT-IN001A-EN-P - August 2012

Catalog Number Explanation

This is the catalog explanation for the LDAT-Series integrated linear thruster.

See

Accessories on page 57

for accessory catalog numbers.

Lubrication
Blank = Standard
Bearing Seal
Blank = Standard
Bearing Protection
Blank = No Cover
S = Strip Cover
Encoder Type
B = Incremental, magnetic scale, 5 μm resolution

D = Absolute, magnetic scale, hiperface

(1)

Winding
D = High Speed
E = Low Speed
Travel
010 = 100 mm (3.94 in.)

060 = 600 mm (23.62 in.)

020 = 200 mm (7.87 in.)

070 = 700 mm (27.56 in.)

030 = 300 mm (11.81 in.) 080 = 800 mm (31.50 in.)
040 = 400 mm (15.75 in.) 090 = 900 mm (35.43 in.)
050 = 500 mm (19.68 in.)
Motor Coil Length
1 = 100 mm (3.94 in.)

4 = 400 mm (15.75 in.)

2 = 200 mm (7.87 in.)

6 = 600 mm (23.62 in.)

3 = 300 mm (11.81 in.)
Frame Size
03 = 030

10 = 100

05 = 050

15 = 150

07 = 075
Version
S = Base Version
Bulletin Number
LDAT = LDAT-Series Integrated Linear Thruster

(1)

Magnetic strip has 1 mm pole pitch. Final resolution when used with a Kinetix® 300 servo drive is 0.488 μm. Absolute encoder is only compatible
with Kinetix 300 single-axis drives.

LDAT - x xx x xxx - x x x x x
