Rockwell Automation LDAT Integrated Linear Thrusters User Manual
Page 51
LDAT-Series Integrated Linear Thrusters 51
Rockwell Automation Publication LDAT-IN001A-EN-P - August 2012
Frame 150
LDAT Cat. No.
Slider Moving Mass kg (lb)
LDAT Cat. No.
Slider Moving Mass kg (lb)
LDAT-S152010-xxx
17.2 (37.85)
LDAT-S154010-xxx
23.2 (51.23)
LDAT-S152020-xxx
20.2 (44.54)
LDAT-S154020-xxx
26.3 (57.92)
LDAT-S152030-xxx
23.2 (51.23)
LDAT-S154030-xxx
29.3 (64.61)
LDAT-S152040-xxx
26.3 (57.92)
LDAT-S154040-xxx
32.3 (71.30)
LDAT-S152050-xxx
29.3 (64.61)
LDAT-S154050-xxx
35.4 (77.99)
LDAT-S152060-xxx
32.3 (71.30)
LDAT-S154060-xxx
38.4 (84.68)
LDAT-S152070-xxx
35.4 (77.99)
LDAT-S154070-xxx
41.4 (91.36)
LDAT-S152080-xxx
38.4 (84.68)
LDAT-S154080-xxx
44.5 (98.05)
LDAT-S152090-xxx
41.4 (91.36)
LDAT-S154090-xxx
47.5 (104.74)
LDAT-S153010-xxx
20.2 (44.54)
LDAT-S156010-xxx
29.3 (64.61)
LDAT-S153020-xxx
23.2 (51.23)
LDAT-S156020-xxx
32.3 (71.30)
LDAT-S153030-xxx
26.3 (57.92)
LDAT-S156030-xxx
35.4 (77.99)
LDAT-S153040-xxx
29.3 (64.61)
LDAT-S156040-xxx
38.4 (84.68)
LDAT-S153050-xxx
32.3 (71.30)
LDAT-S156050-xxx
41.4 (91.36)
LDAT-S153060-xxx
35.4 (77.99)
LDAT-S156060-xxx
44.5 (98.05)
LDAT-S153070-xxx
38.4 (84.68)
LDAT-S156070-xxx
47.5 (104.74)
LDAT-S153080-xxx
41.4 (91.36)
LDAT-S156080-xxx
50.5 (111.43)
LDAT-S153090-xxx
44.5 (98.05)
LDAT-S156090-xxx
53.6 (118.12)
