Communication Setup (Cable Configuration)

4-22

Publication 2755-6.2

Setting Scanner Emulation Synapse Cable Options (Continued)

Convert All to Code 39

When enabled, decoded data is converted and transmitted as Code 39
data.

Note: ASCII from the scanner is transmitted as Code 39 data.

Code 39 to Code 39 Full ASCII

When enabled, Code 39 data is transmitted as Code 39 Full ASCII. The
full ASCII option allows the scanner to output any ASCII character or
control code (including non-printable characters). Refer to Appendix E
for a list of the Code 39 Full ASCII codes.
