Configuring the Scanner
3–5
Publication 2755-6.2
UPC / EAN Options
The following options are available for UPC-A and UPC-E codes:
Transmit UPC-A Check Digit
When enabled, UPC-A symbol data is transmitted with the check digit.
Enabled is the default.
Transmit UPC-E Check Digit
When enabled, UPC-E symbol data is transmitted with the check digit.
Enabled is the default.
Convert UPC-E to UPC-A
When enabled, this option converts UPC-E (zero suppressed) decoded
data to a UPC-A format before sending the data. After conversion,
output data will be affected by UPC-A programming selections such as
preamble and check digit settings. Disabled is the default.
Decode UPC / EAN Supplemental
When enabled, supplemental digits are decoded. If the supplemental
digits are not enabled and a symbol having supplemental digits is read,
the supplemental digits are ignored. On the other hand, if supplemental
digits are enabled, only symbols with supplemental digits are decoded.
Disabled is the default.
Autodiscriminate UPC / EAN with Supplementals
When enabled, supplemental digits are decoded. Both codes with and
without supplemental digits are decoded. Disabled is the default.
