Communication Setup (Cable Configuration) 4-4
Publication 2755-6.2
Setting RS-232 Synapse Cable Options (Continued)
Parity
Set the parity of each ASCII coded character that is transmitted. Make
sure the parity matches the requirements of the host. The selections are:
•
Odd
•
Even
•
Mark (parity bit always set to 1)
•
Space (parity bit always set to 0)
•
None (default)
Check Parity
When enabled, the scanner checks the parity bit.
Number of Stop Bits
The stop bit marks the end of each character transmitted. Set the number
of stop bits to match the host device. The selections are:
•
1 Stop Bit (default)
•
2 Stop Bits
Data Bits
Determines the number of data bits for each ASCII character. The
selections are:
•
7 data bits
•
8 data bits (default)
