2 - connecting and operating scanner, Connecting and operating scanner, Chapter – Rockwell Automation 2755 Decoded Hand-Held Scanner User Manual
Page 20
Chapter
2
Publication 2755-6.2
Connecting and Operating
Scanner
This chapter describes how to connect and test the operation of the
scanner. Sections include:
•
Scanner cable
•
Scanner Emulator Synapse cable connections
•
RS-232 Synapse cable connections
•
Keyboard Wedge Synapse cable connections
•
AdaptaScan Pass Through cable connections
•
Allen-Bradley Enhanced Decoder applications
•
Flexible Interface Module (RB) application
•
PLC application
•
SLC application
Safety
!
ATTENTION: Caution - use of controls or
adjustments or performance of procedures other than
those specified herein may result in hazardous laser
light exposure.
