Connecting and Operating Scanner 2-18
Publication 2755-6.2
Automatic Shutoff
The scanner automatically stops scanning after a bar code symbol has
been read. The length of time the scanner remains on without reading a
label is configurable from 0.5 to 3 seconds. You must release and press
the trigger again to resume scanning.
Audible Response
When scanning a bar code symbol, listen for a single short beep from the
scanner. This beep indicates that the bar code has been successfully
scanned. Refer to the following tables for all other responses:
Beep During Normal Operation
This Response Indicates
1 Beep (short high tone)
Bar code symbol decoded. Scanner audible
response must be enabled.
4 Beeps (long, low tone)
Format or transmission error detected. This error
occurs if the scanner is not properly configured. All
data is ignored. Verify option settings.
Beep During Configuration
This Response Indicates
1 Beep (short high tone)
Bar code symbol decoded. Scanner audible
response must be enabled.
1 Beep (low / high tone)
Input error. Possible causes:
Incorrect bar code scanned
Cancel scanned
Incorrect configuration sequence
1 Beep (high / low tone)
Bar code scanned requiring a value. Scan in the
value using the configuration bar codes.
1 Beep (high / low / high / low tone) Configuration setting successfully changed.
