Configuring the Scanner 3–14
Publication 2755-6.2
Transmit Code ID Character
The code ID identifies a scanned bar code symbol’s code type.
If enabled, the code ID is sent after the prefix and before the bar code
data. The code ID codes are:
A = UPC-A, UPC-E, or EAN 13 F = Interleaved 2 of 5
B = Code 39 G = Discrete 2 of 5
C = Codabar J = MSI Plessey
D = Code 128 K = EAN 128
E = Code 93
Transmit AIM ID Character
When enabled, the AIM code identifier is sent after the prefix and before
the bar code data. The identifier is a three character prefix. Refer to the
following:
Each AIM Code Identifier contains the 3-character string ]cm where:
] = Flag Character (ASCII 93)
c = Code Character (see table below)
m = Modifier (see table on next pages)
Code Character /
Generic Identifier
Code Type
A / ]A0 Code 39
C / ]C0 Code 128
E / ]E0 UPC/EAN
I / ]I0 Interleaved 2 of 5
