Manually Sizing the
Kinetix 6000M System
Step 1: Calculate the IDM unit control power load current for each
IDM unit.
There are three components to the control power load current for each IDM
unit:
• Constant power load
• Digital input loads
• Brake loads
Refer to the IDM unit constant load, brake load, and control power load
specifications shown below.
The digital input load is calculated as follows:
Digital Input Watts =
Where:
Σ
I
inputs
= The sum of all load currents on the digital input power supply to
power the sensor and/or the sensor input current
V = 24V
η
= power supply efficiency = 80%
IDM Unit
Cat. No.
with
Brake
Constant Control Power Load
(W)
Brake Control Power Load
(W)
Output Power Rating
(kW)
MDF-SB1003
No
8
0
1.10
MDF-SB1003
Yes
8
15
1.02
MDF-SB1153
No
8
0
1.15
MDF-SB1153
Yes
8
19.5
1.00
MDF-SB1304
No
8
0
1.39
MDF-SB1304
Yes
8
19.5
1.24
IMPORTANT
Confirm that the total IDM unit control power load is less than the specified
limit for the IPIM module output rating (270 W). See the Kinetix Rotary Motion
Specifications Technical Data, publicatio
.
IMPORTANT
Confirm that the
Σ
I
inputs
value is less than the specified limit (200 mA). See
the Kinetix Rotary Motion Specifications Technical Data, publication
.
Σ
I
inputs
* V *
η
