118 Rockwell Automation Publication 2094-UM003A-EN-P - May 2012
Appendix C Upgrading the Kinetix 6000M System Firmware
Follow these steps to select the IPIM module to upgrade.
1. Make sure the IPIM module will accept a firmware request prior to
attempting the firmware upgrade (see page 117 ).
2. Open your ControlFLASH software.
You can access the ControlFLASH software by either of these methods:
• From the Tools menu in RSLogix 5000 software, choose
ControlFLASH.
• Choose Start>Programs>FLASH Programming Tools>
ControlFLASH.
The Welcome to ControlFLASH dialog box opens.
3. Click Next.
The Catalog Number dialog box opens.
4. Select your IPIM module.
5. Click Next.
