Chapter 2
Introduction to the DL20
2–6
Table 2.A lists the optional accessories.
Table 2.A
Accessories
Item Description Catalog No.
DL20 Cable
Connects Allen-Bradley Industrial Terminals T1 through
T4 or most DTE type dumb terminals.
(Male 25 pin D-shell)
2706-NC1
DL20 Cable
Connects Allen-Bradley Terminals 1784-T45, -T47, -T50,
-T60, other IBM compatibles or DEC VT52, VT100, or
VT101 Terminals. (Female 25-pin D-shell)
Use 25 to 9-Pin AT Adapter with this cable for 1784-T50
or -T60 Industrial or IBM AT computers.
2706-NC2
Data Recorder
Cable
Connects EPI STR-LINK II or III Data Recorders to DL20. 2706-NC3
Data Recorder
Cable
Connects Allen-Bradley 1770-SB or -SA Data Recorders
to DL20.
2706-NC4
A-B Terminal
Cable
Connects A-B Terminals to EPI STR-LINK II or III Data
Recorders. Cable is required if an Allen-Bradley
Industrial Terminal and EPI STR-LINK II or III Data
Recorder is used. Cable is not needed if programming
keyboards (Catalog No. 2706-NK1 or -NK2) are used.
2706-NC5
DL20
Development
Software
Off-line Programming Software for IBM or compatible
computers with 5.25 inch or 3.5 inch disk drive.
2706-NP3
Keyboard Full travel keyboard 2706-NK1
Keyboard Membrane keyboard 2706-NK2
Addressing Bar
Allows DIP switch selection of an address when multiple
DL20s are on an RS-422 network. If Addressing Bar is
not used, address is selected during programming.
2706-NF1
120V Parallel
Input Converter
Connects to the DL20 parallel input port and allows
messages to be triggered using 120 VAC inputs.
Display Mounted Converter
Panel Mounted Converter
2706-NG1
2706-NG2
Enclosure
NEMA Type 12/13 enclosure with mounting holes and
cutout for DL20. Access door has gasket.
One or Two Line Displays
Four Line Displays
2706-NE1
2706-NE2
Flush
Mounting Kits
Eliminates the standard bezel supplied with the display.
One or Two Line Displays
Four Line Displays
2706-NJ1
2706-NJ2
Accessories
