Appendix D
Dimensions
D–7
Figure D.7 provides the dimensions of the optional enclosure.
Figure D.7
Enclosure Dimensions
13.87 (352.3)
2706–NE1
3.87
(98.3)
3.44
(87.4)
6.31
(160.3)
5.96
(151.4)
A B C D
5.68
(144.3)
5.25
(133.4)
8.11
(206)
7.77
(197.4)
2706–NE2
D
8.20 (208.3)
C
0.50 (12.7 mm)
B
Cut Out
1.43
(36.3)
15.88 (403.4)
1.29
(32.8)
D
1.05
(26.7)
A
1.29
(32.8)
13.61 (345.7)
Cut Out
16.19 (411.2)
6–.25
Dia. Holes
(6.4)
Dimensions Inches (Millimeters)
C
Front View
Right Side View
Enclosure
Dimensions
