Chapter 1
Using this Manual
1–2
No special knowledge is needed to enter or edit messages. However, since
the Dataliner message display must be connected to peripheral equipment,
you should be familiar with computer communication terminology.
The following conventions are used:
•
Messages that are displayed on the DL20 are shown centered and in bold
characters. For example:
EDIT?
•
A symbol or word in brackets represent a single key that you should
press. These include keys such as [Y] or [Esc].
•
Since the DL20 can be programmed with a variety of terminals, the
printing on your terminal keyboard may be different than the symbol or
word indicated in brackets. In this manual, we use [Return] to specify the
carriage return function of the keyboard. On your keyboard this may
correspond to the [ENTER] or [
] keys.
•
In the following chapters we refer to the Dataliner DL20 Series Message
Display as the DL20.
Table 1.B lists the additional publications you may require.
Table 1.B
Related Publications
Publication / Catalog
Number
Title
2706-800 Dataliner DL10 Series User Manual
2706-804 Dataliner DL20 Offline Programming Software User Manual
1771-6.5.34 BASIC Module (Catalog No. 1771-DB) User’s Manual
1746-ND005
SLC-500 TM BASIC Module (Catalog No. 1746–BAS)
Design and Integration Manual
1775-6.5.4
Peripheral Communications Module (Catalog No. 1775-GA)
User Manual
Intended Audience
Conventions Used
Related Publications
