Rockwell Automation 2706 DL20 SERIES G USER MANUAL User Manual
Page 172
Appendix G
Application Notes
G–20
Figure G.7
DL20 to High Density DC Output Module (Catalog No. 1771-OBD)
DL20 Terminals
D9 D8
D7 D6
D5 D4
D3 D2
D1
MS1 MS0
GND
DO
00
01
02
03
04
05
06
07
10
11
12
13
14
15
16
17
E
High Density Output Module
(Catalog No. 1771-OBD)
+5
VDC
OUT
00
+24 VDC
!
ATTENTION: Do not connect to terminal 22 (+5 VDC OUT).
Applying any voltage to this terminal will damage the DL20.
