Appendix G
Application Notes
G–12
Table G.B
PLC-5 Sequencer Outputs
PLC 5
Data Table
Address
Binary Radix
N7 Integer File
MSB 15 0 LSB
SQO
Step#
Bit 9
DL20
MS1
Bit 8
DL20
MS0
DL20 Data Lines ①
D7 ..... D0
Decoded
Data Comments
N7:0 0000 0000 0000 0000 0 0 0 0000 0000 0 Initial output step for
SQO.
N7:1 0000 0011 0000 1010 1 1 1 0000 1010 10 Special Msg #10
clears DL20 queue.
N7:2 0000 0010 0000 0001 2 1 0 0000 0001 1 High Byte for variable
data = 256.
N7:3 0000 0001 0001 1111 3 0 1 0001 1111 31 Low Byte for variable
data = 31.
N7:4 0000 0011 0001 0001 4 1 1 17 Triggers message
#17.
N7:9 0000 0000 0001 1111 T4:1.ACC = 287
N7:10 0000 0000 0000 0001
① D8 and D9 are not used in this example.
The steps of the sequencer can be viewed on your PLC-5 programming
software using the Data Monitor Command to view file #N7:0 file array.
The resulting message would be displayed:
TIMER T4:1 = 287
The variable 287 on the above display is the accumulated value for T4:1, free
running timer.
PLC-5 Programming
Examples
