Appendix D
Dimensions
D–2
Figure D.2 provides the overall dimensions of the one and two line DL20.
Figure D.2
One and Two Line DL20 Dimensions
6.65
(168.9 mm)
DIM. ”A’’
SEE
CHART
0.12 TYP.
(3.2 mm)
0.72
(18.3 mm)
13.30
(337.8 mm)
Top View
14.37
(365.0 mm)
DIM. ‘‘B’’
SEE CHART
4.38
(111.2 mm)
Front View
0.125 (3.2 mm) (GASKET THICKNESS)
0.099 (2.5 mm)
(PANEL THICKNESS)
Side View
0.62
(15.7 mm)
3.13
(79.5 mm)
0.62
(15.7 mm)
Six
Mounting
Studs
7.37
(187.2 mm)
Display Type Dimension A Dimension B
One Line
Two Line
1.25 inches
(31.8 mm)
Dimensions Inches (Millimeters)
1.70 inches
(43.2 mm)
10.12 inches
(257.2 mm)
8.81 inches
(223.8 mm)
Overall Dimensions
