Rockwell Automation DeviceNet SEMINAR LAB EX User Manual
Page 4
4
DeviceNet Seminar Lab Exercises
Publication 1787.6.1 - August 1997
Demo Box 2 Description
Demo Box 2 includes the following components.
1203-GK5 communication module
electric motor
power cord (can be
used with 110V or
220V ac outlet)
1305 ac drive
DeviceLink discrete I/O
limit switch
DL10 Dataliner
message display
limit switch
SLC processor
with DeviceNet scanner
SMP-3 solid-state
overload relay
Component (clockwise on drawing)
Catalog number
DL10 Dataliner message display
2706-A11J
SLC processor with DeviceNet scanner
1747-SDN (scanner)
Communication module for power products
1203-GK5 (2 required)
SMP-3 solid-state overload relay
Bulletin 193
Parvalux electric motor
Power cord
1305 ac drive
1305
DeviceLink discrete I/O
1485D-A3C3-C
Oiltight limit switch
802T-WSP
