Rockwell Automation 1747-L5xx SLC 500 Modular Hardware Style User Manual User Manual
Page 106
Publication 1747-UM011G-EN-P - June 2008
106
Installing Your Hardware Components
ATTENTION
If you connect or disconnect the wiring to the terminal
blocks or if you insert or remove the power supply while
the power is on, an electrical arc can occur. This could
cause an explosion in hazardous location installations. Be
sure that power is removed or the area is nonhazardous.
Failure to remove power could cause injury to personnel
and/or equipment.
POWER
POWER
POWER
POWER
PWR OUT +24V dc
PWR OUT COM
120/240V ac
V ac NEUT
Chassis Ground
Not Used
Not Used
+24V dc
V dc NEUT
Chassis Ground
PWR OUT +24V dc
PWR OUT COM
+125V dc
V dc NEUT
Chassis Ground
PWR OUT +24V dc
PWR OUT COM
L1: 85 to 132
/170 to 250V ac
L2: NEUT
Chassis Ground
85 to 132V ac
Jumper
170 to 250V ac
User
Power
User
User
Fuse
Jumper
Selection
100/120 Volts
200/240 Volts
Fuse
Jumper
Selection
85 to 132V ac
170 to 250V ac
1746-P1 and P2
1746-P3
1746-P4
1746-P5, -P6, and -P7
User
Power
User
Power
1746-P5
1746-P6
1746-P7
PWR OUT +24V dc
PWR OUT COM
+48V dc
V dc NEUT
Chassis Ground
Not Used
Not Used
+12/24V dc
V dc NEUT
Chassis Ground
